| Display specifications (module) |
| OC manufacturer/model | BOE\DV550QUB-RH0 |
|
| Screen size/ratio | 55"/16：9 |
|
| Display areaI | 1209.6(H) × 680.4 (V)mm |
|
| Resolution | 3840×2160 |
|
| The whole machine can achieve brightness | 4000nits（Typ.)(without UV)，3200nits（Typ.)(with UV) |
|
| Refresh rate | 60HZ |
|
| LCD screen contrast ratio | 1200:1 | Dynamic contrast ratio: One million to one |
| Display color | 1.07G | 8bit+FRC |
| Transmissivity | 7.6 (Typ.) % |
|
| Pixel pitch | 315(H) ×315(V)um |
|
| LCD screen with viewing angle | ≥178°（CR>10） |
|
| Brightness viewing angle | Horizontal ≥ 68 °, vertical ≥ 62 ° |
|
| Response time | 8ms |
|
| Dimming control mode | Local Diming(192 partitions) |
|
| Color gamut | 68%（Min.），72%（Typ.） NTSC 1931 |
|
| Color correction of production line | auto white balance |
|
| Power consumption | 315w（logic） |
|
| Surface Treatment | AGLR（QWP-POL） |
|
| Weight | 19kg（Theoretical value) |
|
| Special usage environment | 0℃-40℃（No direct sunlight），0℃-30℃（direct sunlight），10%-80%RH |
|
