37 inch P370IVN03.1 high brightness bar type TFT lcd display panel

System Category: LCD/OLED/EPD Panel Modules > TFT-LCM Liquid Crystal Modules

Product Brand: AUO (AU Optoelectronics)

Product Series: P370IVN03

Product Model: P370IVN03.1

Key Description: AUO 37" Long Format VA LCD Module 1920×540 1500nits WLED LVDS 51pins

Product Category: Graphical

Product Tags: Color TFT LCD, High-Brightness LCD, Sunlight-Visible LCD, Cut Bar Screen

Application Products: Digital Signage, Outdoor High Brightness, Cut Strip Screens

Panel Type: a-Si TFT-LCD

Product Composition: LCD Module

Panel size: 37"

Resolution: 1920×540

Width to height ratio: >3:1 (width:height)

Physical shape: Planar rectangle

Display dimensions: 904.32 (width) × 245.34 (height) mm (A.A)

Appearance dimensions: 923.3 (width) × 277.1 (height) mm

Maximum thickness: 30.05 mm

Family of Liquid Crystal States: VA Soft Screen

Polarizer: Transmissive

Panel brightness: 1500 (Typ.)

Transmitting Contrast: 4000:1 (Typical)

Viewing Angle: 89/89/89/89 (Typical) (CR≥10) (Left/Right/Up/Down)

View direction: Full view

Display color: 16.7M/1.07B

Backlight type: WLED

Signal type: LVDS

Signal pin count: 51 Pins

Touch screen: No touch

Operating temperature: -20 ~ 60 °C

Storage temperature: -20 to 60 °C
