Lumineq EL640.480-AA1 CC 10.4 inch high brightness industrial grade EL display panel

The EL640.480-AA1 CC (Alias: EL00004720) is a 10.4-inch EL display launched by Lumineq, featuring self-emission and no touch functionality. This product operates within a temperature range of -60 to 85°C and has a storage temperature range of -60 to 105°C. Its key features include: wide temperature range, lifespan exceeding 50,000 hours, EL640.480-AA1 display with conformal coating, and operational altitude of 18,000 m (58,000 ft.) above sea level. Based on its feature database, this model is recommended for industrial applications. According to the database, mass production began in Q3 2019, and the current status is discontinued. Currently, there are 0 stock records and 0 supplier details for this model, with minimal trading activity. The database first recorded parameters for this model on July 27, 2021, and the last update was made on June 18, 2025. Referring to the product specification document issued by Lumineq on September 30, 2019 (version ED000927D), the EL640.480-AA1 CC has a display resolution of 640(RG)×480 (VGA), an aspect ratio of 4:3 (width:height), and uses vertical striped pixel arrangement. Its active display area measures 211.1 (width) × 158.3 (height) mm, with overall dimensions of 263 (width) × 205.3 (height) mm and a net weight of 800g (Typ.). The product is self-emitting, with a light source lifespan of 50K hours. The EL640.480-AA1 CC employs a Parallel Data (1ch, 4-bit) signal interface, totaling 40 pins, utilizing terminal connections, and operates at a drive voltage of 5.0/12.0V (Typ.) (VCC1/VCC2). Its typical vertical refresh rate (Fv) is 80Hz. The production status indicated in the database is for reference only and should not serve as a basis for user decisions. All panel parameters displayed on ScreenDB® are entered by ScreenDB electronic engineers based on specification documents, with efforts made to minimize errors, but complete accuracy cannot be guaranteed. Please refer to the specification document! For inquiries about the latest production status and technical information for the EL640.480-AA1 CC when developing new products, ScreenDB® recommends consulting Lumineq.
